NGP RCE-15 Return Closed End Set of [2] for Ramp Saddle Thresholds, 15"

NGP RCE-15 Return Closed End Sets for Ramp Saddles, 15" Length

NGP RCE Return Closed End Sets add a polished touch to ramp thresholds. With various lengths available, they can be easily adjusted in the field to fit any ramp assembly. Sold in sets of 2.

• RCE-15: 15" Mill Finish
  RCE-15-DKB: 15" Dark Bronze

Compatible with

• NGP R100MILL
  , R100DKB, R100SIA (Needs to be trimmed to 12")
• NGP R125MILL, R125DKB, R125SIA

NGP (National Guard Products) RCE Features

• BHMA Certified to ANSI/BHMA A156.21 1,000 Lb. Load Test
• Return Closed Ends Provide an Attractive Finished Appearance to Ramps
• Available in Several Lengths and Can Be Trimmed to Accommodate Any Size Ramp Assembly
• Aluminum Alloy 6063, T5 Temper
• ADA Compliant: Barrier-Free Thresholds meet the requirements of the ADA Standard for Accessible Design and ICC/ANSI A117.1 Accessible and Usable Buildings and Facilities.
• CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes
• Positive Pressure: CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80, and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
• ANSI/BHMA CERTIFIED: Certified thresholds comply with the American National Standard for Thresholds ANSI/BHMA A156.21 1,000 lb. load test and are listed in the BHMA Certified Products Directory.

Installation Instructions
