Rixson 99-926-689 CHECKMATE 99 Series Surface Mount Electromagnetic Door Holder, Tri-Voltage (12VDC, 24VAC/DC, 120VAC), Pull Side Mount, 689 Sprayed Aluminum

The Rixson 99-926-689 is a surface-mounted electromagnetic door holder from the CHECKMATE 99 Series, engineered to hold doors open safely and release them automatically during a fire alarm or power interruption. Designed for pull side mounting, this non-handed unit works with a tri-voltage input (12VDC, 24VAC/DC, or 120VAC), making it adaptable across most commercial installations. Finished in 689 sprayed aluminum, it delivers dependable holding force while integrating cleanly with fire and life-safety systems. The non-detectored configuration relies on an external detection system to trigger release, providing a versatile solution for schools, hospitals, offices, and other facilities that require code-compliant door control.

Features

• Surface-mounted electromagnetic door holder for straightforward installation on the pull side of the door.
• Tri-voltage capability accepts 12VDC, 24VAC/DC, or 120VAC for flexible wiring options.
• Non-handed design simplifies specification and works on either door orientation.
• Non-detectored version integrates with an external fire detection or alarm system.
• Durable 689 sprayed aluminum finish suits a wide range of commercial interiors.

Functional Details

The holder maintains contact with the door when energized and releases automatically when power is cut by the connected fire alarm system, allowing the door to close and compartmentalize smoke or fire. As a non-detectored unit, it depends on a separate smoke detection system for activation.

• Holding force of 25 lbs.
• Tri-voltage: 12VDC, 24VAC/DC, 120VAC.
• Current draw: 20mA @ 120VAC, 30mA @ 24VAC, 40mA @ 24VDC, 80mA @ 12VDC.
