Sargent Rim & Mortise Cylinder Product Specs below.

Sargent 34 LA KD Rim Cylinder comes with an LA Keyway, Keyed Different, and 2 Change Keys per Cylinder

Product Specs

Technical Specs

The Sargent 6034 is an LFIC Rim Cylinder Housing for LFIC Large Format Interchangeable Cores, and comes Less Core with a Plastic Construction core in multiple finishes.

• Housing: Solid brass
• Cap: Brass, bronze or stainless steel
• Furnished standard with No. 97 rosette and compression ring
• Includes the same tailpiece and screw hole pattern as the #34 cylinder

Product Specs

Technical Specs

The Sargent 70-34 rim cylinder housing is an SFIC Small Format Interchangeable Core Housing, sold less core,  with a plastic construction core for Rim Exit Device Trims.

• Brass cylinder and housing
• Furnished with No. 97 rosette, break off screws and back plate
• Housing accepts 6 or 7 pin core
• Mounting holes located to match SARGENT hardware

Product Specs

Technical Specs

Sargent 40 Series Mortise Cylinders are high quality conventional cylinders available in a number of different keyways and finishes.

Sargent mortise cylinders are made from solid brass and have a brass, bronze or stainless steel face cap available in all architectural finishes. They are furnished standard with number 97 rosette and compression spring. Optional collars and spacers are available and ordered separately. Sargent mortise cylinders are available in lengths ranging from 1-1/8″ through 3″, minimum length for 7-Pin is 1-1/4″. They are provided standard with Sargent offset cam number 13-0664, other cams are available.

Technical Specs

Sargent 6042 Mortise Cylinder Housing, 1-1/4 In. LFIC, Standard Sargent Cam, Accepts a 6 Pin Interchangeable Core, Furnished Less Core

Sargent mortise cylinder housings are made from solid brass and have a brass, bronze, or stainless steel face cap available in all architectural finishes. They are furnished standard with a number 97 rosette and compression spring. Optional collars and spacers are available and ordered separately. Sargent mortise cylinders are available in lengths ranging from 1-1/8" through 3", the minimum length for 7-Pin is 1-1/4". They are provided standard with Sargent offset cam number 13-0664, other cams are available.

Product Specs

Sargent 70-43 Mortise Cylinders 1-3/8" Mortise Cylinder "SFIC" Accepts Small Format 6-7 Pin Interchangeable Core, Furnished Less Core

Sargent 40 Series Mortise Cylinders are high-quality conventional cylinders available in a number of different keyways and finishes.

Sargent mortise cylinders are made from solid brass and have a brass, bronze, or stainless steel face cap available in all architectural finishes. They are furnished standard with a number 97 rosette and compression spring. Optional collars and spacers are available and ordered separately. Sargent mortise cylinders are available in lengths ranging from 1-1/8″ through 3″, the minimum length for 7-Pin is 1-1/4″. They are provided standard with Sargent offset cam number 13-0664, other cams are available.

Technical Specs
