Description
Schlage ND50-JD-OME Cylindrical Entrance/Office Lock, Omega Lever, Schlage FSIC Full Sized Interchangeable Core, Less Core, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed
The Schlage ND50-JD-OME Cylindrical Entrance/Office Lock combines heavy-duty Grade 1 performance with the clean look of the Omega lever for demanding commercial openings. This non handed lock is configured with a Schlage FSIC full sized interchangeable core prep and ships less core, making it a practical choice when cores are supplied separately. It is built with a 2-3/4 inch backset and a 4-7/8 inch strike for standard commercial door applications. As part of the Schlage ND Series cylindrical lock lineup, the ND50-JD-OME entrance/office function is designed for strength, serviceability, and dependable daily use.
Features
- ND50-JD-OME entrance/office function cylindrical lock for commercial applications.
- Omega lever trim provides a distinctive lever design within the Schlage ND Series.
- Prepared for a Schlage FSIC full sized interchangeable core cylinder.
- Supplied less core so the interchangeable core can be furnished separately.
- Built with a 2-3/4 inch backset for compatible door preparation.
- Includes a 4-7/8 inch strike for installation on standard commercial frames.
- Grade 1 construction supports heavy-duty performance requirements.
- Non handed design allows installation on either right-hand or left-hand doors.
Functional Details
The ND50 entrance/office function is commonly used where outside access must be controlled while allowing convenient egress from the inside. In this FSIC configuration, the lock is prepared to accept a Schlage full sized interchangeable core, which supports fast rekeying and simplified key system management in commercial facilities.
- Outside lever locked by push button inside. Turning inside lever or closing door releases button. Inside lever always unlocked.
- Push button re-locks automatically when door is closed.
Included Components
This lock is supplied less core and prepared for a Schlage FSIC full sized interchangeable core. It is configured with a 2-3/4 inch backset and a 4-7/8 inch strike, and the non handed chassis supports flexible installation.
Product Specifications
| Manufacturer | Schlage |
|---|---|
| Series | ND Series |
| Model | ND50-JD-OME |
| Product Type | Cylindrical Entrance/Office Lock |
| Lever Design | Omega Lever |
| Core Type | Schlage FSIC Full Sized Interchangeable Core |
| Core Provided | Less Core |
| Backset | 2-3/4 Inch |
| Strike | 4-7/8 Inch Strike |
| Handing | Non Handed |
| Grade | Grade 1 |
| ANSI Number | F109 |
| UL Listing Type | UL listed for 3-hour fire door |
| BAA Qualified | No |
| Origin | Made in Mexico with USA and global components |
| Unit of Measure | Each |
| Limited Warranty | 10 Year Mechanical Warranty and 3 Year Electro Mechanical Warranty |
| SKU | ND50-JD-OME |
Technical Specifications
| Lock Function | ND50 Entrance/Office |
|---|---|
| ANSI Function Number | F109 |
| Chassis Type | Cylindrical |
| Lever Style | OME Omega |
| Cylinder Preparation | FSIC Full Sized Interchangeable Core |
| Core Status | Less Core |
| Backset Dimension | 2-3/4 Inch |
| Strike Dimension | 4-7/8 Inch |
| Handing | Non Handed |
| BHMA Grade | Grade 1 |
| Fire Rating | 3 Hour |
| Door Thickness Range | 1-5/8 Inch to 2-1/8 Inch |
| Latch Front | 1-1/8 Inch x 2-1/4 Inch |
| Strike Type | ANSI Strike |
| Cross Bore | 2-1/8 Inch |
| Edge Bore | 1 Inch |
| Latch Throw | 1/2 Inch |
