Schlage ND50-JD-TLR Cylindrical Entrance/Office Lock, Tubular Lever, Schlage FSIC Full Sized Interchangeable Core, Less Core, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed

The Schlage ND50-JD-TLR Cylindrical Entrance/Office Lock is a heavy-duty Grade 1 lock built for commercial openings that need dependable entrance and office security. This non handed lock features a tubular lever design, Schlage FSIC full sized interchangeable core preparation, and is supplied less core for keying flexibility. It is configured with a 2-3/4 inch backset and a 4-7/8 inch strike to match standard commercial door applications. As part of the Schlage ND Series, the ND50-JD-TLR combines durable cylindrical lock construction with the strength, serviceability, and performance expected for high-traffic institutional, office, and commercial environments.

Features

• ND50-JD-TLR entrance/office function is designed for commercial doors that require keyed outside access and secure inside operation.
• Heavy-duty cylindrical lock construction provides the durability associated with the Schlage ND Series.
• Tubular lever trim offers a familiar lever design suited for frequent use in commercial settings.
• Prepared for a Schlage FSIC full sized interchangeable core to support fast rekeying and key system flexibility.
• Supplied less core so the interchangeable core can be furnished separately to match the facility keying system.
• Built with a 2-3/4 inch backset for standard commercial door preparation compatibility.
• Includes a 4-7/8 inch strike for proper frame alignment on compatible openings.
• Certified Grade 1 performance for demanding institutional and commercial applications.
• Non handed design allows installation on either right-hand or left-hand doors.

Functional Details

The ND50 entrance/office function is intended for doors that need controlled entry from the outside while allowing normal egress from the inside. This function is commonly used on offices, main entries, and similar commercial openings where security, durability, and convenient day-to-day operation are important.

• Outside lever unlocked by key from outside or by rotating inside lever.
• Inside lever always unlocked.
• Push button locks outside lever until unlocked by key or by rotating inside lever.
• Inside push button may be depressed and released with door open for automatic locking of outside lever upon door closing.

Included Components

This lock is supplied less core and is prepared to accept a Schlage FSIC full sized interchangeable core. It is configured with a 2-3/4 inch backset and a 4-7/8 inch strike, and the non handed chassis supports installation on either door hand without field handing changes.
