Description
Schlage ND70JD-LAT Cylindrical Classroom Lock, Latitude Lever, Schlage FSIC Full Sized Interchangeable Core, Less Core, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed
The Schlage ND70JD-LAT Cylindrical Classroom Lock combines heavy-duty Grade 1 performance with the clean look of a Latitude lever for demanding commercial openings. This cylindrical classroom lock is built for reliable operation and is configured for a Schlage FSIC full sized interchangeable core, supplied less core for keying flexibility. It includes a 2-3/4 inch backset and a 4-7/8 inch strike to suit standard commercial door preparations. The ND70JD-LAT is non handed for easier installation and field flexibility, making it a practical choice for schools, offices, and institutional facilities that need durable classroom security with interchangeable core convenience.
Features
- ND70JD-LAT cylindrical classroom lock function is designed for commercial openings that require controlled access and dependable durability.
- Latitude lever trim provides a modern straight lever design suited for institutional and commercial interiors.
- Prepared for a Schlage FSIC full sized interchangeable core for convenient key system management and core changes.
- Supplied less core so the interchangeable core can be furnished separately to match the facility keying system.
- Configured with a 2-3/4 inch backset for compatibility with common commercial door preparations.
- Includes a 4-7/8 inch strike for proper frame preparation on compatible openings.
- Grade 1 construction meets the highest ANSI/BHMA performance grade for cylindrical locks.
- Non handed design allows installation on either right-hand or left-hand doors.
Functional Details
The ND70JD classroom function is intended for classroom and similar applications where the outside lever is locked or unlocked by key, while the inside lever remains free for immediate egress at all times. This function supports controlled entry without restricting exit, which is important in educational and commercial settings.
- Outside lever locked and unlocked by key.
- Inside lever always unlocked.
Included Components
This Schlage ND70JD-LAT cylindrical classroom lock is supplied less core and prepared for a Schlage FSIC full sized interchangeable core. It is configured with a 2-3/4 inch backset and a 4-7/8 inch strike, and its non handed design helps simplify ordering and installation.
Product Specifications
| Manufacturer | Schlage |
| Series | ND Series |
| Model | ND70JD-LAT |
| Product Type | Cylindrical Classroom Lock |
| Lever Design | Latitude Lever |
| Core Format | Schlage FSIC Full Sized Interchangeable Core |
| Core Included | Less Core |
| Handing | Non Handed |
| Grade | Grade 1 |
| ANSI Number | F84 |
| UL Listing Type | UL listed for 3-hour fire door |
| Unit of Measure | Each |
| Origin | Made in USA |
| BAA Qualified | Yes |
| Limited Warranty | 10 Year Mechanical Warranty, 3 Year Electro Mechanical Warranty |
Technical Specifications
| Backset | 2-3/4 in |
| Strike | 4-7/8 in |
| Door Thickness | 1-3/8 in to 2 in |
| Latch Front | 1-1/8 in x 2-1/4 in |
| Crossbore | 2-1/8 in |
| Edge Bore | 1 in |
| Cylinder Type | FSIC full sized interchangeable core |
| Function | ND70JD classroom |
| Handing | Non handed |
| Fire Rating | 3 hour |
| Cycle Testing | Over 16,000,000 cycles |
| ANSI Grade | Grade 1 |
