Description
Schlage ND80BD-OME Cylindrical Storeroom Lock, Omega Lever, SFIC Prep Less Core, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed
The Schlage ND80BD-OME Cylindrical Storeroom Lock is a heavy-duty Grade 1 lockset built for demanding commercial openings that require dependable security and long service life. This configuration includes the Omega lever design, SFIC prep less core construction for small format interchangeable core compatibility, a 2-3/4 inch backset, and a 4-7/8 inch strike. The ND80BD storeroom function is non handed for flexible installation and is part of Schlage’s ND Series cylindrical lock line, making it a strong choice for schools, offices, healthcare facilities, and other high-traffic applications where controlled exterior access is required.
Features
- ND80BD storeroom function is designed for controlled access on commercial doors.
- Omega lever trim provides a distinctive lever style within the Schlage ND Series.
- SFIC prep less core configuration is prepared for a small format interchangeable core and is supplied less core.
- 2-3/4 inch backset supports standard commercial door preparations requiring this latch dimension.
- 4-7/8 inch strike provides the specified strike size for frame preparation compatibility.
- Grade 1 construction meets the highest ANSI/BHMA grade for cylindrical locks.
- Non handed design allows installation on either right-hand or left-hand doors.
- Cylindrical lock chassis is engineered for heavy-duty institutional and commercial use.
Functional Details
The ND80BD storeroom function keeps the outside lever rigid at all times, requiring a key for entry from the outside while allowing free egress from the inside. This function is commonly used on doors that need to remain secure from the corridor side without restricting exit from within the room.
- Outside lever rigid.
- Entrance by key only.
- Inside lever always unlocked.
Included Components
This Schlage ND80BD-OME lock is supplied as a cylindrical lockset with Omega lever trim, SFIC prep less core preparation, a 2-3/4 inch backset, and a 4-7/8 inch strike. The interchangeable core is not included.
Product Specifications
| Manufacturer | Schlage |
| Series | ND Series |
| Model | ND80BD-OME |
| Product Type | Cylindrical Storeroom Lock |
| Function | Storeroom |
| Lever Design | Omega Lever |
| Keying / Core Prep | SFIC Prep Less Core |
| Handing | Non Handed |
| Grade | ANSI/BHMA Grade 1 |
| ANSI Number | F86 |
| UL Listing Type | UL listed for A label single doors, up to 4'0" x 10'0" |
| Backset | 2-3/4 Inch |
| Strike | 4-7/8 Inch Strike |
| Door Thickness | 1-3/8" to 2" |
| Unit of Measure | Each |
| Origin | Made in USA of domestic and imported materials |
| BAA Qualified | Yes |
| Limited Warranty | 10 Year Mechanical Warranty, 3 Year Electro Mechanical Warranty where applicable |
Technical Specifications
| Lock Function Number | ND80BD |
| ANSI Function | F86 |
| BHMA Grade | Grade 1 |
| Backset | 2-3/4" |
| Strike Size | 4-7/8" |
| Door Thickness Range | 1-3/8" to 2" |
| Latch Throw | 1/2" |
| Deadlocking Latch | Yes |
| Handing | Non Handed |
| Core Format | Small Format Interchangeable Core Prep, less core |
| Lever Style | Omega |
| Fire Door Listing | 3 hours |
| Cycle Testing | 3,100,000 cycles |
| Latch Front | 1-1/8" x 2-1/4" |
| Strike Type | ANSI strike |
