Schlage ND80JD-ATH-RX Cylindrical Storeroom Lock, Athens Lever, Request to Exit, Schlage FSIC Full Sized Interchangeable Core, Less Core, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed

The Schlage ND80JD-ATH-RX Cylindrical Storeroom Lock is a heavy-duty Grade 1 lock designed for demanding commercial openings that require dependable security and controlled access. This configuration includes the Athens lever, Request to Exit capability, and preparation for a Schlage FSIC Full Sized Interchangeable Core, supplied less core for flexible keying. It is built with a 2-3/4 inch backset and a 4-7/8 inch strike, making it a practical choice for standard commercial door applications. The non handed design simplifies installation, while the ND Series construction delivers the durability and performance expected from Schlage cylindrical locks.

Features

• ND80JD function provides a cylindrical storeroom lock configuration for secure commercial openings.
• Athens lever trim offers a clean, durable lever design suited for institutional and commercial use.
• Request to Exit monitoring supports access control applications where egress signaling is required.
• Prepared for a Schlage FSIC full sized interchangeable core for convenient rekeying and key system management.
• Supplied less core so the interchangeable core can be ordered separately to match the facility key system.
• Built with a 2-3/4 inch backset for compatibility with common commercial door preparations.
• Includes a 4-7/8 inch strike for proper frame alignment and latch engagement.
• Grade 1 construction meets high-performance commercial hardware requirements.
• Non handed design allows installation on either right-hand or left-hand doors.

Functional Details

The ND80JD storeroom function keeps the outside lever rigid at all times, with entry by key only, while the inside lever remains free for immediate egress. In this RX configuration, the lock also provides Request to Exit signaling to interface with access control and monitoring systems. The Schlage FSIC full sized interchangeable core preparation allows the cylinder core to be changed quickly without replacing the lock body.

• Outside lever rigid.
• Entrance by key only.
• Inside lever always unlocked.
• RX switch available.
• FSIC - Full Size Interchangeable Core.

Included Components

This lock is supplied less core and is prepared to accept a Schlage FSIC full sized interchangeable core. It includes the lockbody, Athens lever trim, and strike sized at 4-7/8 inch for the specified 2-3/4 inch backset configuration.
