Schlage ND80JD-BRK Cylindrical Storeroom Lock, Boardwalk Lever, Schlage FSIC Full Sized Interchangeable Core, Less Core, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed

The Schlage ND80JD-BRK Cylindrical Storeroom Lock is a heavy-duty Grade 1 lock built for high-traffic commercial openings that require dependable security and durability. This configuration includes the Boardwalk lever design, Schlage FSIC Full Sized Interchangeable Core preparation, and is supplied less core for flexible keying setup. It is furnished with a 2-3/4 inch backset and a 4-7/8 inch strike to support standard commercial door preparations. The ND80JD-BRK is non handed for easier installation and is part of Schlage’s ND Series, known for strong performance, consistent operation, and long service life in demanding applications.

Features

• ND80JD-BRK cylindrical storeroom lock function is designed for commercial openings that require secure outside access control.

• Boardwalk lever trim provides a modern lever style within the Schlage ND Series.

• Prepared for a Schlage FSIC full sized interchangeable core for convenient core management and rekeying flexibility.

• Supplied less core so the interchangeable core can be furnished separately to match the key system requirements.

• Configured with a 2-3/4 inch backset for standard commercial door preparation.

• Includes a 4-7/8 inch strike for compatible frame installation.

• Grade 1 construction supports heavy-duty use in demanding commercial environments.

• Non handed design allows installation on either right-hand or left-hand doors.

Functional Details

The storeroom function keeps the outside lever rigid at all times, requiring a key for entry from the exterior side, while the inside lever remains free for immediate egress. This makes the ND80JD-BRK a practical choice for secured rooms, utility spaces, and other commercial applications where controlled access and safe exit are both required.

• Outside lever rigid.

• Entrance by key only.

• Inside lever always unlocked.

Included Components

This Schlage ND80JD-BRK lock is supplied less core and prepared to accept a Schlage FSIC Full Sized Interchangeable Core. It is also configured with a 2-3/4 inch backset and a 4-7/8 inch strike for installation on compatible commercial doors and frames.
