Schlage ND80JD-BRK-RX Cylindrical Storeroom Lock, Boardwalk Lever, Request to Exit, Schlage FSIC Full Sized Interchangeable Core, Less Core, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed

The Schlage ND80JD-BRK-RX Cylindrical Storeroom Lock is a heavy-duty Grade 1 lockset built for high-traffic commercial openings that require dependable security and controlled access. This configuration includes the Boardwalk lever, Request to Exit capability, and preparation for a Schlage FSIC Full Sized Interchangeable Core, supplied less core for keying flexibility. It is furnished with a 2-3/4 inch backset and a 4-7/8 inch strike, making it well suited for commercial door applications that need durable performance and compatibility with interchangeable core systems. The non handed design also helps simplify installation and field preparation.

Features

• ND80JD storeroom function provides secure outside access control for commercial openings.
• Boardwalk lever trim offers a clean, durable lever design for institutional and commercial use.
• Request to Exit monitoring adds exit signaling capability for access control applications.
• Prepared for a Schlage FSIC full sized interchangeable core for flexible key system management.
• Supplied less core so the interchangeable core can be ordered separately to match the facility keying system.
• Includes a 2-3/4 inch backset for compatibility with thicker commercial door preparations.
• Furnished with a 4-7/8 inch strike for proper frame engagement.
• Grade 1 construction supports heavy-duty commercial performance requirements.
• Non handed design allows installation on either right-hand or left-hand doors.
• Cylindrical lock chassis supports bored door applications with strong, serviceable construction.

Functional Details

The ND80JD storeroom function is designed to keep the outside lever rigid at all times, requiring a key for entry while allowing free egress from the inside. In this RX configuration, the lock also provides a Request to Exit signal for integration with electrified hardware and access control systems. The Schlage FSIC full sized interchangeable core preparation supports quick core changes without replacing the lock body.

• Outside lever rigid.
• Entrance by key only.
• Inside lever always unlocked.
• Inside lever retracts latch.
• RX - Request to exit switch retracts latch bolt and signals use of inside lever.

Included Components

This lock is supplied as a cylindrical storeroom lockset with Boardwalk lever trim, RX Request to Exit feature, Schlage FSIC full sized interchangeable core preparation, a 2-3/4 inch backset latch, and a 4-7/8 inch strike. It is furnished less core, allowing the interchangeable core to be selected separately for the intended key system.
