Schlage ND80JD-BRW Cylindrical Storeroom Lock, Broadway Lever, Schlage FSIC Full Sized Interchangeable Core, Less Core, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed
The Schlage ND80JD-BRW Cylindrical Storeroom Lock with Broadway lever is a heavy-duty Grade 1 cylindrical lock built for demanding commercial openings. This ND80JD function is designed for storeroom applications and is configured for a Schlage FSIC full sized interchangeable core, supplied less core for key system flexibility. It includes a 2-3/4 inch backset and a 4-7/8 inch strike, making it suitable for standard commercial door preparations that require dependable security and durability. As a non handed lock, it simplifies installation while delivering the trusted performance and strength associated with the Schlage ND Series.
Features
- ND80JD storeroom function provides secure outside access control for commercial openings.
- Broadway lever design offers a modern straight lever style within the Schlage ND Series.
- Prepared for a Schlage FSIC full sized interchangeable core for flexible keying and core management.
- Supplied less core so the interchangeable core can be furnished separately to match the facility key system.
- Configured with a 2-3/4 inch backset for compatible door preparation requirements.
- Includes a 4-7/8 inch strike for standard frame installation.
- Grade 1 construction meets high-use commercial performance requirements.
- Non handed design allows installation on either right-hand or left-hand doors.
Functional Details
The ND80JD storeroom function keeps the outside lever rigid at all times and requires a key for entry from the exterior side. The inside lever always allows free egress, making this function a common choice for secured utility rooms, storage areas, and other restricted spaces in commercial buildings.
- Outside lever fixed.
- Entrance by key only.
- Inside lever always unlocked.
Included Components
This lock is supplied less core and is prepared to accept a Schlage FSIC full sized interchangeable core. The lock is configured with a 2-3/4 inch backset and includes a 4-7/8 inch strike.
Product Specifications
| Manufacturer | Schlage |
| Series | ND Series |
| Model | ND80JD-BRW |
| Lock Type | Cylindrical Lock |
| Function | Storeroom |
| Lever Design | Broadway Lever |
| Core Type | Schlage FSIC Full Sized Interchangeable Core |
| Core Included | Less Core |
| Backset | 2-3/4 Inch |
| Strike | 4-7/8 Inch Strike |
| Handing | Non Handed |
| Grade | ANSI/BHMA Grade 1 |
| ANSI Number | F86 |
| UL Listing Type | UL Listed for 3-hour fire door |
| Origin | Made in USA of domestic and imported materials |
| Unit of Measure | Each |
| BAA Qualified | Yes |
| Limited Warranty | 10 Year Mechanical Warranty, 3 Year Electro Mechanical Warranty |
Technical Specifications
| ANSI Function Number | F86 |
| BHMA Grade | Grade 1 |
| Backset Dimension | 2-3/4 Inch |
| Strike Size | 4-7/8 Inch |
| Door Thickness Range | 1-3/8 Inch to 2-1/8 Inch |
| Cross Bore | 2-1/8 Inch |
| Edge Bore | 1 Inch |
| Latch Front | 1-1/8 Inch x 2-1/4 Inch |
| Strike Standard | 1-1/4 Inch x 4-7/8 Inch |
| Latch Bolt Throw | 1/2 Inch |
| Fire Rating | 3 Hour |
| Cycle Testing | 3,100,000 cycles |
| Handing | Non Handed |
| Core Preparation | FSIC Full Sized Interchangeable Core |
