Schlage ND80JD-OME-RX Cylindrical Storeroom Lock, Omega Lever, Request to Exit, Schlage FSIC Full Sized Interchangeable Core, Less Core, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed

The Schlage ND80JD-OME-RX Cylindrical Storeroom Lock is a heavy-duty Grade 1 lock built for high-traffic commercial openings that require reliable security and controlled egress. This configuration includes the Omega lever, Request to Exit capability, and preparation for a Schlage FSIC full sized interchangeable core, supplied less core for keying flexibility. It is furnished with a 2-3/4 inch backset and a 4-7/8 inch strike, making it well suited for standard commercial door applications. The ND80JD-OME-RX is non handed for easier installation and is part of the proven Schlage ND Series cylindrical lock platform.

Features

• ND80JD-OME-RX cylindrical storeroom lock function supports secure access control for commercial openings.
• Omega lever design provides a durable and recognizable Schlage lever style.
• Request to Exit capability allows integration with access control and egress systems.
• Prepared for a Schlage FSIC full sized interchangeable core for convenient core management.
• Supplied less core so the interchangeable core can be ordered separately to match facility keying.
• Includes a 2-3/4 inch backset for compatibility with common commercial door preparations.
• Furnished with a 4-7/8 inch strike for proper frame engagement.
• Grade 1 construction is designed for demanding institutional, commercial, and public building use.
• Non handed design simplifies ordering, inventory, and installation.

Functional Details

This storeroom function keeps the outside lever rigid at all times, requiring key access for entry while allowing free egress from the inside. The Request to Exit feature is designed for use with electronic access control systems, signaling egress activity when the inside lever is operated.

• Outside lever rigid at all times.
• Entrance by key only.
• Inside lever always unlocked.
• RX switch monitors inside lever rotation.

Included Components

This lock is supplied less core and is prepared to accept a Schlage FSIC full sized interchangeable core. It includes the cylindrical lock chassis, Omega lever trim, 2-3/4 inch backset latch arrangement, and 4-7/8 inch strike as specified for the ND80JD-OME-RX configuration.
