Description
Schlage ND80JD-SPA Cylindrical Storeroom Lock, Sparta Lever, Schlage FSIC Full Sized Interchangeable Core, Less Core, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed
The Schlage ND80JD-SPA Cylindrical Storeroom Lock with Sparta lever is a heavy-duty Grade 1 cylindrical lock built for high-traffic commercial openings that require dependable security and long service life. This ND80JD-SPA configuration includes preparation for a Schlage FSIC full sized interchangeable core and is supplied less core, making it a practical choice for facilities using interchangeable core key systems. It is furnished with a 2-3/4 inch backset and a 4-7/8 inch strike, and its non handed design helps simplify installation and inventory management across a wide range of door applications.
Features
- ND80JD storeroom function is designed for commercial openings that need secure outside access control with free egress from the inside.
- Sparta lever trim provides a clean, durable lever design suited for institutional and commercial use.
- Prepared for a Schlage FSIC full sized interchangeable core for facilities that use interchangeable core keying systems.
- Supplied less core so the interchangeable core can be ordered separately to match the building key system.
- Includes a 2-3/4 inch backset for doors requiring the longer commercial backset option.
- Furnished with a 4-7/8 inch strike for proper frame preparation compatibility.
- Grade 1 construction meets the highest ANSI/BHMA grade for cylindrical locks.
- Non handed design allows installation on either right-hand or left-hand doors.
Functional Details
The ND80JD storeroom function keeps the outside lever rigid at all times, requiring a key for entry, while the inside lever always remains free for immediate egress. This function is commonly used on service doors, stock rooms, and other secured areas where controlled entry and safe exit are both required.
- Outside lever rigid.
- Entrance by key only.
- Inside lever always unlocked.
Included Components
This lock is supplied less core and is prepared to accept a Schlage FSIC full sized interchangeable core. It includes the cylindrical lock chassis, Sparta lever trim, 2-3/4 inch backset latch configuration, and 4-7/8 inch strike.
Product Specifications
| Manufacturer | Schlage |
|---|---|
| Series | ND Series |
| Model | ND80JD-SPA |
| Lock Type | Cylindrical Lock |
| Function | Storeroom |
| Lever Design | Sparta Lever |
| Core Type | Schlage FSIC Full Sized Interchangeable Core |
| Core Included | Less Core |
| Grade | ANSI/BHMA Grade 1 |
| Handing | Non Handed |
| Backset | 2-3/4 Inch |
| Strike | 4-7/8 Inch Strike |
| ANSI Number | F86 |
| UL Listing Type | UL listed for 3-hour fire door |
| Origin | Made in USA of domestic and imported materials |
| Unit of Measure | Each |
| BAA Qualified | Yes |
| Limited Warranty | 10 Year Mechanical Warranty, 3 Year Electro Mechanical Warranty |
| SKU | ND80JD-SPA |
Technical Specifications
| ANSI Function Number | F86 |
|---|---|
| Backset | 2-3/4 Inch |
| Strike Size | 4-7/8 Inch |
| Door Thickness Range | 1-3/8 Inch to 2-1/8 Inch |
| Cross Bore | 2-1/8 Inch |
| Edge Bore | 1 Inch |
| Latch Front | 1-1/8 Inch x 2-1/4 Inch |
| Strike Dimension | 1-1/4 Inch x 4-7/8 Inch |
| Latch Throw | 1/2 Inch |
| Lever Projection | 2-15/16 Inch |
| Rose Diameter | 3-7/16 Inch |
| Cylinder Format | FSIC Full Sized Interchangeable Core |
| Handing | Non Handed |
| Fire Rating | 3 Hour |
| Cycle Testing | 3,100,000 cycles |
