Schlage ND80PD-ATH-RX Cylindrical Storeroom Lock, Athens Lever, Request to Exit, Schlage "C", Keyed Different, [2] Change Keys, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed

The Schlage ND80PD-ATH-RX Cylindrical Storeroom Lock is a heavy-duty Grade 1 cylindrical lock built for high-traffic commercial openings that require dependable security and request to exit capability. This configuration includes the Athens lever design, RX request to exit monitoring, a Schlage "C" keyway, keyed different cylindering, and [2] change keys for day-to-day key control. It is supplied with a 2-3/4 inch backset and a 4-7/8 inch strike, and the non handed chassis helps simplify installation across a wide range of door applications. The ND80PD function combines strong storeroom security with the durability expected from Schlage ND Series hardware.

Features

• ND80PD storeroom function provides secure outside access while supporting commercial cylindrical lock applications.
• Athens lever trim offers a modern lever style within the Schlage ND Series platform.
• RX request to exit capability allows the lock to signal egress-related monitoring functions.
• Schlage "C" keyway is included for standard Schlage keying compatibility.
• Keyed different cylindering provides an individual key combination for this lock.
• [2] change keys are included for immediate operation and key management.
• 2-3/4 inch backset supports standard commercial door preparation requirements.
• 4-7/8 inch strike is included for the specified frame strike application.
• Grade 1 construction meets high-performance commercial hardware standards.
• Non handed design allows installation on either right-hand or left-hand doors.

Functional Details

The ND80PD storeroom function keeps the outside lever rigid at all times, requiring a key for entry, while the inside lever remains free for immediate egress. In this RX configuration, the lock also provides request to exit signaling for integration with access control, monitoring, or alarm-related systems.

• Outside lever rigid.
• Entrance by key only.
• Inside lever always unlocked.
• RX switch monitors inside lever rotation.

Included Components

This Schlage ND80PD-ATH-RX lock is supplied with the Athens lever trim, Schlage "C" keyed cylinder in a keyed different configuration, [2] change keys, a 2-3/4 inch backset latch, and a 4-7/8 inch strike. Its non handed design helps reduce inventory complexity and speeds installation in the field.
