Schlage ND80PD-BRK Cylindrical Storeroom Lock, Boardwalk Lever, Schlage "C", Keyed Different, [2] Change Keys, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed

The Schlage ND80PD-BRK Cylindrical Storeroom Lock with Boardwalk lever is a heavy-duty Grade 1 lock built for demanding commercial openings. This ND80PD-BRK configuration features the Schlage "C" keyway, keyed different operation, and includes [2] change keys for secure key control right out of the box. Designed with a 2-3/4 inch backset and a 4-7/8 inch strike, it fits common commercial door preparations while delivering the strength and reliability expected from the Schlage ND Series. Its non handed design also helps simplify installation and inventory management across a wide range of applications.

Features

• ND80PD-BRK cylindrical storeroom lock function is designed for secure commercial openings that require controlled entry.
• Boardwalk lever trim provides a modern lever design within the Schlage ND Series platform.
• Schlage "C" keyway offers compatibility with Schlage C key systems.
• Keyed different cylinder means each lock is furnished with its own unique key combination.
• Includes [2] change keys for immediate operation and key distribution.
• 2-3/4 inch backset supports standard commercial door preparation requirements.
• 4-7/8 inch strike is included for compatible frame installation.
• Grade 1 construction meets the highest ANSI/BHMA grade for cylindrical locks.
• Non handed design allows installation on either right-hand or left-hand doors.

Functional Details

The storeroom function keeps the outside lever rigid at all times and requires a key for entry, while the inside lever remains free for immediate egress. This makes the ND80PD-BRK a practical choice for doors that need dependable security without restricting safe exit from the inside.

• Outside lever rigid.
• Entrance by key only.
• Inside lever always unlocked.

Included Components

This lock is supplied keyed different with a Schlage "C" cylinder, [2] change keys, a 2-3/4 inch backset latch, and a 4-7/8 inch strike. Its non handed design helps reduce the need to stock separate left- and right-hand versions.
