Schlage ND80JD-EL-BRK Cylindrical Electrified Storeroom Lock, Boardwalk Lever, 12-24V VDC, Fail Safe, Schlage FSIC Full Sized Interchangeable Core, Less Core, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed

The Schlage ND80JD-EL-BRK Cylindrical Electrified Storeroom Lock is a heavy-duty Grade 1 lock designed for demanding commercial openings that require electric access control and dependable mechanical security. This configuration includes the Boardwalk lever, 12-24V VDC operation, and fail safe functionality for applications where the outside lever is unlocked when power is applied as specified. It is prepared for a Schlage FSIC full sized interchangeable core and supplied less core, with a 2-3/4 inch backset and 4-7/8 inch strike for proper door preparation. The ND80JD-EL-BRK is non handed for easier installation and flexible field use.

Features

• ND80JD-EL-BRK cylindrical electrified storeroom lock built for commercial-duty access control applications.
• Boardwalk lever design provides a modern Schlage lever style for institutional and commercial openings.
• 12-24V VDC electrified operation supports low-voltage access control integration.
• Fail safe configuration allows the lock to operate according to fail safe electrified function requirements.
• Prepared for a Schlage FSIC full sized interchangeable core for convenient core management.
• Supplied less core so the interchangeable core can be ordered separately to match the key system.
• Configured with a 2-3/4 inch backset for compatible door preparation.
• Includes a 4-7/8 inch strike for proper frame alignment and latching.
• Grade 1 construction meets high-use commercial performance requirements.
• Non handed design allows installation on either right-hand or left-hand doors.

Functional Details

This electrified storeroom function is designed for controlled access openings where electric operation is required along with the security and durability of the Schlage ND Series. The ND80JD-EL function combines storeroom performance with remote electrical control, and the fail safe setup is intended for openings that must release according to the electrical state defined by the system design.

• Electrically unlocks outside lever.
• Inside lever always free for immediate egress.
• Outside lever is rigid at all times.
• Latchbolt retracted by key from outside or by inside lever.
• Inside lever retracts latchbolt at all times.
• Available in either fail safe or fail secure.
• Field selectable for 12 or 24V DC.

Included Components

This Schlage ND80JD-EL-BRK configuration is supplied less core and is prepared to accept a Schlage FSIC full sized interchangeable core. It is furnished with a 2-3/4 inch backset and a 4-7/8 inch strike as part of the listed configuration.
