Schlage ND80JD-EL-LON Cylindrical Electrified Storeroom Lock, Longitude Lever, 12-24V VDC, Fail Safe, Schlage FSIC Full Sized Interchangeable Core, Less Core, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed
The Schlage ND80JD-EL-LON Cylindrical Electrified Storeroom Lock is a heavy-duty Grade 1 lockset built for demanding commercial openings that require controlled access and dependable performance. This configuration includes the Longitude lever, 12-24V VDC electrified operation, and fail safe function for applications where the outside lever is unlocked when power is applied or interrupted according to system design. It is prepared for a Schlage FSIC full sized interchangeable core and is supplied less core for flexible keying. This non handed lock also includes a 2-3/4 inch backset and 4-7/8 inch strike for standard commercial door prep compatibility.
Features
- ND80JD-EL function provides a cylindrical electrified storeroom lock for controlled commercial access.
- Longitude lever trim offers a modern straight lever design from the Schlage ND Series.
- 12-24V VDC operation supports low-voltage electrified hardware applications.
- Fail safe operation allows the lock to work with life-safety and access control system requirements where specified.
- Prepared for a Schlage FSIC full sized interchangeable core for convenient rekeying and core management.
- Supplied less core so the interchangeable core can be ordered separately to match the facility key system.
- 2-3/4 inch backset fits common commercial door preparations.
- 4-7/8 inch strike is included for frame compatibility.
- Grade 1 construction meets heavy-duty ANSI/BHMA performance standards.
- Non handed design allows installation on either right-hand or left-hand doors.
Functional Details
The ND80JD-EL electrified storeroom function is designed for access-controlled openings where the outside lever is managed electrically while the inside lever remains free for egress. This fail safe configuration is used where the opening must release upon loss of power, making it suitable for security and safety-sensitive applications when properly specified.
- Outside lever is locked by default.
- Inside lever always unlocked for immediate egress.
- Fail safe operation unlocks the outside lever when power is removed.
- Operates on 12 or 24VDC.
Included Components
This lock is supplied less core and is prepared to accept a Schlage FSIC full sized interchangeable core. The listed configuration includes the 2-3/4 inch backset and 4-7/8 inch strike for installation on compatible commercial doors and frames.
Product Specifications
| Manufacturer | Schlage |
|---|---|
| Series | ND Series |
| Model | ND80JD-EL-LON |
| Product Type | Cylindrical Electrified Storeroom Lock |
| Lever Design | Longitude Lever |
| Function | Electrified Storeroom, Fail Safe |
| Core Type | Schlage FSIC Full Sized Interchangeable Core |
| Core Included | Less Core |
| Backset | 2-3/4 Inch |
| Strike | 4-7/8 Inch Strike |
| Handing | Non Handed |
| Grade | Grade 1 |
| ANSI Number | F80 |
| UL Listing Type | UL listed for 3-hour fire door |
| Unit of Measure | Each |
| Origin | Made in USA or Mexico |
| BAA Qualified | No |
| Limited Warranty | 10 Year Mechanical Warranty, 3 Year Electro Mechanical Warranty |
| SKU | ND80JD-EL-LON |
Technical Specifications
| Voltage | 12-24V VDC |
|---|---|
| Backset Dimension | 2-3/4 Inch |
| Strike Size | 4-7/8 Inch |
| ANSI Grade | Grade 1 |
| ANSI Function Number | F80 |
| Door Thickness Range | 1-5/8 Inch to 2-1/8 Inch |
| Cross Bore | 2-1/8 Inch |
| Edge Bore | 1 Inch |
| Latch Front | 1-1/8 Inch x 2-1/4 Inch |
| Strike Dimension | 1-1/4 Inch x 4-7/8 Inch |
| Cylinder Preparation | FSIC Full Sized Interchangeable Core |
| Handing | Non Handed |
| Fire Rating | 3 Hour |
| Electrical Function | Fail Safe |
| Lever Style | Longitude |
