Schlage ND80PD-EU-ATH Cylindrical Electrified Storeroom Lock, Athens Lever, 12-24V VDC, Fail Secure, Schlage "C", Keyed Different, [2] Change Keys, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed

The Schlage ND80PD-EU-ATH Cylindrical Electrified Storeroom Lock is a heavy-duty Grade 1 solution designed for controlled access openings that require dependable electrical operation and keyed security. This lock features the Athens lever trim, 12-24V VDC operation, and fail secure functionality, allowing the outside lever to remain locked during power loss. It is supplied with the Schlage "C" keyway, keyed different, and includes [2] change keys for day-to-day key control. With a 2-3/4 inch backset, 4-7/8 inch strike, and non handed design, this ND Series lock offers flexible installation and strong performance for commercial applications.

Features

• ND80PD-EU electrified storeroom function provides controlled access with remote electrical operation.
• Athens lever design offers a distinctive straight return style for commercial door applications.
• 12-24V VDC operation supports low-voltage electrified hardware systems.
• Fail secure operation keeps the outside lever locked when power is removed.
• Schlage "C" keyway is included for standard Schlage cylinder compatibility.
• Keyed different configuration provides an individual key combination for this lock.
• [2] change keys are included for immediate keying convenience.
• 2-3/4 inch backset fits common commercial door preparations requiring the longer latch dimension.
• 4-7/8 inch strike is included for proper frame engagement.
• Grade 1 construction meets high-use commercial performance requirements.
• Non handed design allows installation on either right-hand or left-hand doors.

Functional Details

The ND80PD-EU storeroom function is designed for doors that need secure outside access with free egress from the inside. In fail secure mode, the outside lever remains locked when power is off and becomes electrically unlocked when energized, while the inside lever remains free for safe exit at all times.

• Outside lever is normally locked.
• Inside lever always unlocked.
• Turning inside lever retracts latch.
• Outside lever is unlocked by electric current and remains unlocked while energized.
• Outside lever is locked when power is off.
• Latchbolt retracted by key in outside lever or by turning inside lever.
• Inside lever always free for immediate egress.

Included Components

This lock is supplied with the Schlage "C" keyway cylinder, keyed different configuration, and [2] change keys. It is also prepared with a 2-3/4 inch backset latch and 4-7/8 inch strike for installation on compatible commercial doors and frames.
