Schlage ND80PD-EU-OME Cylindrical Electrified Storeroom Lock, Omega Lever, 12-24V VDC, Fail Secure, Schlage "C", Keyed Different, [2] Change Keys, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed

The Schlage ND80PD-EU-OME Cylindrical Electrified Storeroom Lock combines heavy-duty Grade 1 performance with the convenience of electrified access control in a non handed cylindrical lockset. This configuration features the Omega lever, 12-24V VDC operation, and fail secure functionality for controlled entry. It is supplied with the Schlage "C" keyway, keyed different, and includes [2] change keys. The lock is configured with a 2-3/4 inch backset and a 4-7/8 inch strike, making it a strong fit for commercial openings that require a durable storeroom function with dependable Schlage ND Series construction.

Features

• ND80PD-EU electrified storeroom function supports access control with 12-24V VDC operation.
• Fail secure design keeps the outside lever locked during power loss while allowing electrical release when energized.
• Omega lever trim provides a modern Schlage ND Series lever design.
• Schlage "C" keyway is supplied keyed different for individual keying.
• Includes [2] change keys for immediate key control at installation.
• Built with a 2-3/4 inch backset for the specified door preparation.
• Furnished with a 4-7/8 inch strike for compatible frame applications.
• Grade 1 construction meets heavy-duty commercial performance requirements.
• Non handed design simplifies installation and field application.

Functional Details

The ND80PD-EU electrified storeroom function is designed for doors that need outside access controlled electrically while maintaining free egress from the inside. In fail secure mode, the outside lever remains locked when power is removed, and electrical power unlocks the outside lever for authorized entry. The inside lever remains operable for safe exit.

• Outside lever locked until unlocked by electric solenoid.
• Inside lever always unlocked.
• Inside lever retracts latchbolt.
• Auxiliary latch deadlocks latchbolt.
• Latchbolt retracted by key in outside lever when in locked position.
• Outside lever rigid at all times.
• Fail secure.

Included Components

This lockset is supplied with the Schlage "C" keyway, keyed different cylindering, [2] change keys, a 2-3/4 inch backset latch arrangement, and a 4-7/8 inch strike as specified in the product configuration.
