Description
Schlage ND80PD-OME Cylindrical Storeroom Lock, Omega Lever, Schlage "C", Keyed Different, [2] Change Keys, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed
The Schlage ND80PD-OME Cylindrical Storeroom Lock is a heavy-duty Grade 1 lock built for demanding commercial openings that require dependable security and long service life. This configuration includes the Omega lever design, Schlage "C" keyway, keyed different cylinder, and [2] change keys for immediate key control out of the box. It is supplied with a 2-3/4 inch backset and a 4-7/8 inch strike, and its non handed construction helps simplify installation on either door hand. As part of the Schlage ND Series, the ND80PD storeroom function is designed for controlled exterior access with durable cylindrical lock performance.
Features
- ND80PD storeroom function keeps the outside lever rigid at all times for keyed entry control.
- Omega lever trim provides a distinct commercial lever design within the Schlage ND Series.
- Schlage "C" keyway is included for compatibility with standard Schlage key systems.
- Keyed different cylinder means this lock operates on its own unique key combination.
- Supplied with [2] change keys for immediate use and key management.
- Includes a 2-3/4 inch backset for the specified door preparation.
- Furnished with a 4-7/8 inch strike for frame reinforcement and latch engagement.
- Grade 1 construction meets the highest ANSI/BHMA grade for cylindrical locks.
- Non handed design allows installation on either right-hand or left-hand doors.
Functional Details
The ND80PD storeroom function is intended for doors that must remain locked on the outside while allowing free egress from the inside. The outside lever is fixed and does not retract the latch unless operated by key, while the inside lever always allows immediate exit.
- Outside lever rigid.
- Entrance by key only.
- Inside lever always unlocked.
Included Components
This Schlage ND80PD-OME Cylindrical Storeroom Lock includes the Omega lever trim, Schlage "C" keyed different cylinder, [2] change keys, a 2-3/4 inch backset latch, and a 4-7/8 inch strike. Its non handed design helps reduce stocking complexity and supports installation on either door hand.
Product Specifications
| Manufacturer | Schlage |
| Series | ND Series |
| Model | ND80PD-OME |
| Product Type | Cylindrical Storeroom Lock |
| Function | Storeroom |
| Lever Design | Omega Lever |
| Keyway | Schlage "C" |
| Keying | Keyed Different |
| Included Keys | 2 Change Keys |
| Handing | Non Handed |
| Grade | ANSI/BHMA Grade 1 |
| ANSI Number | F86 |
| UL Listing Type | UL listed for 3-hour fire door |
| Origin | Made in USA |
| BAA Qualified | Yes |
| Unit of Measure | Each |
| Limited Warranty | 10 Year Mechanical Warranty, 3 Year Electro Mechanical Warranty |
Technical Specifications
| Backset | 2-3/4 in |
| Strike Size | 4-7/8 in |
| Door Thickness | 1-3/8 in to 2 in |
| Cross Bore | 2-1/8 in |
| Edge Bore | 1 in |
| Latch Front | 1-1/8 in x 2-1/4 in |
| Strike Dimensions | 1-1/4 in x 4-7/8 in |
| Latch Throw | 1/2 in |
| Cylinder Type | 6-pin conventional cylinder |
| Handing | Non handed |
| Function Number | ND80PD |
| ANSI Function | F86 |
| Fire Rating | 3 hour |
| Cycle Test | 3,100,000 cycles |
