Description
Schlage ND80PD-OME-RX Cylindrical Storeroom Lock, Omega Lever, Request to Exit, Schlage "C", Keyed Different, [2] Change Keys, 2-3/4 Inch Backset, 4-7/8 Inch Strike, Grade 1, Non Handed
The Schlage ND80PD-OME-RX Cylindrical Storeroom Lock is a heavy-duty Grade 1 solution built for dependable security in high-traffic commercial openings. This configuration includes the Omega lever design, Request to Exit capability, and a Schlage "C" keyway with keyed different operation and [2] change keys included. It is supplied with a 2-3/4 inch backset and a 4-7/8 inch strike for standard commercial door prep, and its non handed design helps simplify installation and field application. As part of the Schlage ND Series, this cylindrical storeroom lock is engineered for durability, consistent performance, and code-conscious access control.
Features
- ND80PD function provides cylindrical storeroom lock operation for controlled entry and free egress.
- Omega lever trim offers a modern lever style suited for commercial applications.
- Request to Exit monitoring supports access control and egress system integration.
- Schlage "C" keyway is included for standard Schlage keying compatibility.
- Keyed different configuration provides an individual key combination for the lock.
- [2] change keys are included with the lock.
- 2-3/4 inch backset fits common commercial door preparations.
- 4-7/8 inch strike is included for frame compatibility.
- Grade 1 construction is designed for demanding commercial use.
- Non handed design allows installation on either right-hand or left-hand doors.
Functional Details
The ND80PD storeroom function keeps the outside lever rigid at all times, requiring key access for entry while allowing immediate egress from the inside. The RX Request to Exit feature is designed for use with access control systems by signaling lever operation from the inside.
- Outside lever fixed.
- Entrance by key only.
- Inside lever always unlocked.
- Inside lever retracts latch.
- RX - Request to Exit switch monitors inside lever operation.
Included Components
This lockset includes the Schlage ND80PD-OME-RX cylindrical lock body, Omega lever trim, Schlage "C" keyway cylinder keyed different, [2] change keys, 2-3/4 inch backset latch, and 4-7/8 inch strike.
Product Specifications
| Manufacturer | Schlage |
|---|---|
| Series | ND Series |
| Model | ND80PD-OME-RX |
| Product Type | Cylindrical Storeroom Lock |
| Lever Design | Omega Lever |
| Request to Exit | RX - Request to Exit switch monitors inside lever operation |
| Keyway | Schlage "C" |
| Keying | Keyed Different |
| Included Keys | [2] Change Keys |
| Backset | 2-3/4 Inch |
| Strike | 4-7/8 Inch Strike |
| Grade | ANSI/BHMA Grade 1 |
| Handing | Non Handed |
| ANSI Number | F86 |
| UL Listing Type | UL listed for 3-hour fire door |
| BAA Qualified | Yes |
| Origin | Made in U.S.A. of U.S. and imported materials |
| Unit of Measure | Each |
| Limited Warranty | 10 Year Mechanical Warranty, 3 Year Electro Mechanical Warranty |
| SKU | ND80PD-OME-RX |
Technical Specifications
| ANSI/BHMA Grade | Grade 1 |
|---|---|
| ANSI Function Number | F86 |
| Backset | 2-3/4 in |
| Strike Size | 4-7/8 in |
| Door Thickness Range | 1-3/8 in to 2-1/8 in |
| Crossbore Diameter | 2-1/8 in |
| Edge Bore Diameter | 1 in |
| Latch Front | 1-1/8 in x 2-1/4 in |
| Strike Dimensions | 1-1/4 in x 4-7/8 in |
| Latch Throw | 1/2 in |
| Cylinder Type | Conventional Cylinder |
| Keyway Type | Schlage C |
| Handing | Non Handed |
| Fire Rating | 3 Hour |
| Cycle Test | 3,100,000 cycles |
| Lever Style | OME - Omega |
| Electrical Option | RX Request to Exit |
