Name: Schlage ND92PD-RHO Entrance VANDLGARD Lock, Rhodes Lever, Schlage "C" Keyway
Brand: SCHLAGE
SKU: ND92PDRHO626
Price: 863.00 CAD
Availability: InStock

Fence Screen Height *

Standard 3′ ft. Fence Screen Colors *

Black FenceScreen Size *

Beige FenceScreen Size *

Grey FenceScreen Size *

Brown FenceScreen Size *

White FenceScreen Size *

Standard 8′ ft. Fence Screen Colors *

Green FenceScreen Size *

Black FenceScreen Size *

Beige FenceScreen Size *

Gray FenceScreen Size *

Brown FenceScreen Size *

White FenceScreen Size *

Standard 4′ ft. Fence Screen Colors *

Green FenceScreen Size *

Black FenceScreen Size *

Beige FenceScreen Size *

Gray FenceScreen Size *

Brown FenceScreen Size *

White FenceScreen Size *

Standard 5′ ft. Fence Screen Colors *

Green FenceScreen Size *

Black FenceScreen Size *

Beige FenceScreen Size *

Gray FenceScreen Size *

Brown FenceScreen Size *

White FenceScreen Size *

Standard 6′ ft. Fence Screen Colors *

Green FenceScreen Size *

Black FenceScreen Size *

Beige FenceScreen Size *

Gray FenceScreen Size *

Brown FenceScreen Size *

White FenceScreen Size *

Function	92 Entrance Lock
Function Family	Entrance
ANSI Function	F109 - Entry/Office
Lever/Knob Design	RHO Rhodes Lever
Lever/Knob Design Family	Straight Return Lever
Rose/Escutcheon Design	3-7/16" Rose Diameter
Rose/Escutcheon Dimensions	3-7/16"
Cylinder Type	Cylinder
Num Pins	6
Key(s)	Cut
Num of Keys	2
Handing	Non-handed
Door Thickness	1-5/8 In. to 2-1/8 In.
Std. Latch Number	13-247
Std. Latch Type	Deadlatch
Std. Latch Backset Dim	2-3/4 In.
Latch Bore Diameter	1 In.
Lock Face Size	1-1/8 In. x 2-1/4 In.
Bolt Projection	1/2 In.
Bore Hole Diameter	2-1/8 In.
Std. Strike Number	10-025
Std. Strike Type	ANSI Strike
Std. Strike Height	4-7/8 In.
Std. Strike Width	1-1/4 In.
Screws	Wood/Machine Screws
Product Type	Cylindrical Lock

Manufacturer	Schlage
SKU	ND92PD RHO
Grade	Grade 1
Installation	Commercial
Origin	Mexico
Unit of Measure	Each
UL Listing Type	UL/cUL Listed
ANSI Number	ANSI A156.2 Series 4000, Grade 1
BAA Qualified	Yes
Limited Warranty	10 Years
Fire Rated	3 Hours {A}
ADA Compliance	Yes

Schlage ND92PD-RHO Entrance VANDLGARD Lock, Rhodes Lever, Schlage "C" Keyway

Schlage ND92PD-RHO Entrance VANDLGARD Lock, Rhodes Lever, Schlage "C" Keyway

Technical Specs

Product Specs

ND Mechanical Overview
